End-of-line test machines that verify every traction motor before it leaves your line — electrical safety, performance and NVH checks with automatic pass/fail decisions and full data logging.
Our motor EOL testing machines combine automatic fixturing, electrical connection and a configurable test sequence in a single safe station. Results are evaluated against your limits, stored against the motor serial number and shared with your MES — so only verified motors reach your customers.
Choose the test sequence your motor and customer specifications require.
Dielectric strength and insulation resistance tests between windings and housing.
Current, speed and direction checks during a controlled no-load run.
Precision measurement of phase resistance and inductance with balance evaluation.
Vibration and acoustic analysis to catch bearing, rotor and assembly defects.
Back-EMF waveform, amplitude and phase-balance checks with the motor driven externally.
Hall sensor, encoder or resolver signal and alignment verification.
A fully automatic sequence from loading to pass/fail decision and data upload.
Operator loads the motor; its serial number is scanned and linked to the test record.
No-load run with current and speed checks, plus back-EMF evaluation.
Pneumatic clamping and automatic connection of power and signal leads.
Noise and vibration signatures analysed to detect mechanical defects.
Hi-pot and insulation resistance tests between windings and housing.
Automatic evaluation against your recipe limits for each motor model.
Phase resistance, inductance and balance measured against limits.
Passed motors are labelled; failures are locked out and data sent to MES.
In-wheel BLDC hub motors for electric two-wheelers.
Permanent-magnet synchronous motors for EVs.
Brushless DC motors for e-mobility and industrial use.
AC induction traction and industrial drive motors.
Concept design, cycle-time study, build, validation and installation — one partner for the whole project.
Barcode, laser marking and process data logging ready for your MES and Industry 4.0 goals.
Every machine is designed around your product, output target and quality plan — not a catalogue model.
Operator training, spares and responsive after-sales support from our team in Gurgaon.
Motionworks Robotics designs and builds motor EOL (end-of-line) testing machines in Gurgaon (Gurugram), Haryana, for EV and industrial motor manufacturers. Each motor EOL testing machine is custom engineered around your motor, output target and quality plan, and can integrate hi-pot and insulation resistance, winding resistance and inductance, back-EMF and phase balance, no-load run, NVH and sensor verification tests.
Recipe-based testing handles multiple motor models on one machine, with automatic pass/fail, reject lock for failed parts, label printing for passed motors, and test reports, SPC and data export to your MES or cloud.
Can’t find your answer? Talk to our engineers — we’re happy to help.
Our motor EOL testing machines can integrate hi-pot and insulation resistance, winding resistance and inductance, back-EMF and phase balance, no-load run (current, speed and direction), noise and vibration (NVH) analysis, and Hall sensor, encoder or resolver verification.
In-wheel BLDC hub motors for electric two-wheelers, PMSM traction motors for EVs, BLDC motors for e-mobility and industrial use, and AC induction traction and industrial drive motors.
Yes. Recipe-based testing lets one machine handle multiple motor models, with limits set for each model.
Failed motors are locked out automatically, passed motors are labelled, and all test data is stored against the motor serial number and sent to your MES.
Our team is at 75-A, Sector-35, Gurgaon-122004, Haryana, India. Call +91-124-2212680 or request a quote to discuss your motor EOL testing machine.
Share your product drawings and target output — our engineers will propose the right line concept.
A brief explanation of the work we do and the solutions we provide — a few are one of their kind in the industry. Find yours today.
Motionworks Robotics designs and builds automated assembly machines, precision gauging, laser marking, robotic automation, EV manufacturing machines and special purpose machines — the joy of automation, made in India.
